Part # Approx. Weight (LBS.) Clearing Width Closed (in.) Clearing Width Open (in.) Overall Road Width (Angled) (in.) Snow Clearing Width (Angled) (in.) Wing Width (Each) Mouldboard Height Max Operating Weight (lbs.) SB6205W1020 4,435 120 240 115 195 36" 53" 60,000 SB6205W1222 4,760 144 264 135 215 60" 53" 60,000 SB6205W1424 5,030 168 288 155 235 60" 53" 60,000 SB6205W1626 5,485 192 312 175 255 60" 53" 60,000 SB6205W1828 5,855 216 336 195 275 60" 53" 60,000 SB6205W2030 6,220 240 360 215 295 60" 53" 60,000
2 Year Warranty
Designed for harsh conditions, HLA Snow backs its 3000, 4000, 5000, and 6000 series blades with a 2 Year Commercial Warranty.
Infinitely and independently adjustable, our wings are rugged enough to stay put and give you control of any situation.
35° Angle with Crossover Relief Valve Protection
Allows the blade to be rotated 35° in either direction, while the cross over relief valve protects from structural damage to either the machine or property.
Floating End Plate Edge
Floating endplate edges follow surface contour for confident snow clearing.
Allows blade to follow ground contours for better clearing performance.
Precision engineered curve rolls and folds snow. This reduces sticking, side tracking and spill over.
Nitrate Rods on Angle Cylinders
Nitrate rods on angle cylinders.
Replaceable, Reversible Cutting Edge
Our cutting edges are designed to be easily replaceable and are reversible to give you twice the life.
Note: Replace endcaps along with cutting edges to prevent streaming.
Wing edges are not reversible.
(non Edge Flex only)
Rotary Actuators - PATENTED
These rugged units come from the construction industry and deliver up to 54,200 in-lb. of torque at 3000 PSI to hold the wings in place.
Cast Highway Skid Shoes
Standard on 4203W, 4205W, 5203W, 5205W, and 6205W SnowWings without Edge Flex. Cast high tensile long wear skid shoes provide excellent longevity and performance suited for heavy duty clearing on concrete or asphalt.
Spring Trip Cutting Edge
Allows cutting edge to trip back if struck by hidden object limiting damage.
Tire Protection System - PATENTED
Our Tire Protection System means that you get the most out of your Snow Wing while keeping the air in your tires. The system automatically protects from unintended damaging collisions between your front tires and end plates. The end plates are automatically rotated away from the tires so the operator can focus on clearing snow and worry less about damaging equipment.
Floating Blade Hinge
This option adds a mechanical float to the blade. This allows the blade to better follow the surface contour. The float is designed to be simply locked out when not needed by rolling the blade forward.
Double Electric Selector Valve
Allows the control of each wing to be operated independently. 12V or 24V coils available. Includes in cab mount electro-hydraulic harness kit.
Quick Attach Frame Kits
Quick attach frame kits are available for most makes. Call dealer for details.
Rubber Cutting Edge
The optional rubber cutting edge is available for select models.
Available on all SnowWing models and the 3000, 4000, 5000, & 6000 series SnowBlades.
Carbide Cutting Edges
Carbide edges are designed for heavy commercial use, this non reversible cutting edge is suited for heavy duty clearing on concrete or asphalt.
NOTE: Colour added to image to highlight carbide.
The optional Curb Runner runs along the front face of the curb, preventing the edge of the wing from catching on any edges.
Add this to your blade for better visibility and blade position awareness.
The new Foot Switch is a direct replacement for the 3-way toggle switch traditionally used to control the diverter valve on SnowWing plows.
Available as a field install kit to retrofit from a 3-way toggle switch, or as an upgrade option with a new plow order.
AR400 Large Pad Skid Shoe
Large pad style skid shoe for better floatation on soft surfaces
NOTE: Available on non Edge Flex models.
Edge Flex Models
Available in Edge Flex. Segmented cutting edges available with standard hardox or heavy duty carbide.
